Waste Type: Domestic Waste
Average Emissions Rates: Not to exceed EU Standard Limits (Total dust “mg/m3”: 30; Sulphur Dioxide: 200;Nitrogen Dioxide: 400; Carbon Monoxide: 100)
Minimum Burn Rate: 2,000 kg per day (up to 1,500-person camp); top loading
Insulation: high-grade fireproof insulation backing.
Loading/Ash removal: Manual loading and ash removal from side door or tray.
External Finish: high-temperature coat
Controls: Fully automatic control through PLC system for burn chamber temperature; burn and cool down
cycles
Operational Temperature: 850-133000
Burner/s: Fully automatic, high-efficiency burners with electronic ignition, flame recognition sensors with
combustion control features; Burner Fuel: Diesel; Electrical supply: Single, 220-240V; or 3-phase, 380-415V,50-60Hz
Complete kit with chimney, filters (if applicable) and 2 years spare parts.
Manufacturer specification, photographs/catalogue and technical datasheet shall be provided
